reliable stability and excellent optics

Worktops, 38mm thick

For both worktops, this is Minimum depth 70mm at a maximum worktop length of 3,000mm. From 3,000mm length is the Minimum depth 120mm.

Worktops in APD design

The worktop with decorative edge is front and side with a straight decorative edge, which is 1.5mm thick. The delivery standard for 90° outside corners is a square version. A rounded version with an outer radius of 20 mm is optionally available at no extra cost. If inner and outer corners are to be rounded, they are given an inner radius of 30 mm and an outer radius of 20 mm by default. A square version of the inside corner is also available for an additional charge AP-IEK / 9354. The decor edge is available in all worktop decors.

Worktops APN with N-edge

The worktop APN with N-edge has one rounded front edge, this is laterally coated with a straight decorative edge. An inserted N-edge can also be supplied at an additional cost.

corner worktops

A design as a corner worktop is possible with a 135° corner for diagonal base units. The corner worktops are available for the APN and APD worktops in the following sizes: 800 x 800, 900 x 900, 1050 x 1050. Please note that a corner sink cannot be installed in the 800 x 800 diagonal cabinet. Tongue and groove connections are not included in the price, and deviations from the standard design are charged with a surcharge of 20% per change.

Machining on worktops APD & APN

The following finishes are possible on worktops with decorative edges and N-edges:

• Outside and inside curves with radii deviating from the standard radius
  A notice: If inner and outer corners are to be rounded, they are given an inner radius of 30mm and an outer radius of 20mm by default.
  Please indicate deviations from this standard radii. (Dimensions and sketch required)
• angular versions of the inner corner
• bevels
• Bevels on worktops with edge assignments
• Bevels, Z-shape on worktops with edge assignments for diagonal Z-shape cabinets
• additional edge assignment on worktops at the rear, on the side and at notches
  A notice: here the maximum length is 2500mm and the minimum width is 100mm
• tongue and groove connection
• Cut-outs for built-in hobs, sinks, built-in washbasins or ventilation grilles
  A notice: Device type and cut-out dimensions must be specified here. Cutouts must be sealed with sealing tape on site.
  Not permitted for the installation of flush hobs or sinks
• Notches with edge assignments
  A notice: With bevels of up to 150°, the edge allocation can be freely selected on each side. In the case of edge assignment with N-edge, APN-A or APN-AS is also calculated. For bevels > 150°, the edge allocation must be uniform (APN or APD) and the radius must be at least 20 mm for APD. The minimum width for U-notches rounded on the inside is 450 mm.
• Decorative edge for worktops
  Please state the edge color number!

Slimline worktop

The APSLN Slim Line worktop, 16 mm thick, is coated in the same color on both sides and has a 1.2 mm thick decorative edge all around. The minimum size is 250 x 200 mm and the maximum length is 3400 mm.
The following information must be observed here: Rounding, chamfering, cutouts and notches are not possible. Tables, counters and worktop extensions are not possible! Only square worktop shapes possible! Flush installation of hobs and sinks in Slim Line worktops is not possible.

Machining on Slim Line worktops

The following processing is possible on the Slim Line worktop:

• tongue and groove connections
• Slim Line installation set for cooker cabinets
• Slim Line installation set for handleless LINE N cooktop cabinets
• Decorative edge for worktop Slim Line

Extra countertop

The innovative functional layer of the Xtra worktop prevents water from penetrating and swelling. In addition, a flush installation of technically approved hobs and built-in sinks is possible (only applies to 38 mm). All Xtra worktops with a thickness of 38 mm are now equipped with the microPLUS® surface with an antibacterial effect.

Cut-outs for flush installation in Xtra worktops

The following cut-outs for flush installation are possible:

• Cut-out for the flush installation of Sinks and hobs from the nobilia range
  A notice: Flush cut-outs are only permitted for sinks and hobs that are marked accordingly. Please pay attention to the symbol for flush installation in the list of appliances and sinks. Flush cut-outs are only possible in Xtra worktops with a thickness of 38 mm.
• Cut-out for the flush installation of third-party sinks (according to technical release list)
• Cut-out for the flush installation of third-party hobs (according to technical release list)
  A notice: Flush cut-outs can only be made for technically approved hobs and sinks. Our technical release list for flush installation can be found on the nobilia extranet. This is regularly updated on the extranet and in the kitchen planning systems in retail. Flush cut-outs are only possible in Xtra worktops with a thickness of 38 mm.

Xtra Ceramic worktop

The 16 mm thick worktop consists of 6 mm thick, solid ceramic on a 10 mm lightweight carrier layer made from recycled glass. In combination with an impact-resistant design edge, Xtra Ceramic is ideal for extra demands in everyday kitchen life.
As with the Xtra worktop, flush-fitting installation of technically approved hobs and built-in sinks is possible.
The worktop in Xtra Ceramic Design is 16 mm thick and has a width of 250 - 3,100 mm. The worktop has a design edge on the front and sides that is 1.2 mm thick.

Machining on Xtra Ceramic worktops

The following processing options are available for Xtra Ceramic worktops:

• notches
• U-shaped notches
• Full depth bevels
• additional edge assignment
• drilling
• socket drilling
• plate joint
• Cut-outs for countertop washbasins, sockets, sinks and support hobs
• Cut-out for the flush installation of sinks and hobs
  A notice: Flush cut-outs can only be made for technically approved hobs and sinks. Please pay attention to the symbol for flush installation in the list of appliances and sinks. Our technical release list for flush installation can be found on the nobilia extranet. This is regularly updated on the extranet and in the kitchen planning systems in retail.

quartz stone countertop

Quartz stone is waterproof even without impregnation. The surfaces are particularly easy to care for and hygienic. As with the Xtra worktop, flush-fitting installation of technically approved hobs and built-in sinks is possible.
Binding drawings with specific dimensions are required for the order release of plans with quartz stone worktops. Subsequent processing on site is only possible with appropriate tools for quartz stone and personal protective equipment.

Worktop APQS quartz stone, 12 mm thick

The surface and front edge of the 12 mm thick quartz stone worktop are polished with a double bevel.
The side and rear edges are also available with a polished double bevel for a surcharge.

Worktop APQ quartz stone, 38 mm thick

The surface of the 38 mm thick quartz stone worktop is polished and the front edge is mitred with a bevel.
For a surcharge, the side and rear edges are also available mitered with a chamfer.

Processing of quartz stone countertops

The following finishes are possible on the quartz worktop:

• outside curves
• notches
• U-shaped notches
• bevels
• Bevels, Z shape
• additional edge processing
• drilling
• plate joint
• Plate joint diagonally
• Cut-outs for sockets, countertop washbasins, sinks and support hobs
• Cut-outs for the flush installation of sinks and hobs
  A notice: Flush cut-outs can only be made for technically approved hobs and sinks. Please pay attention to the symbol for flush installation in the list of appliances and sinks. Our technical release list for flush installation can be found on the nobilia extranet. This is regularly updated on the extranet and in the kitchen planning systems in retail.

Pultplatten

The desk top in the worktop decor for screwing onto the worktop and is coated on both sides with laminate. The panel is 100 mm thick, has a polymer edge all the way around, has a maximum depth of 1,200 mm and a maximum width of 1,800 mm.

Attachment table, planning example 1

Calculation example:
APD90: 1600 x 900 mm,
1 x APD-K: Surcharge for rear edge allocation 700 mm,
1 x AP-R: surcharge for rounding radius 450 mm, 1 x AP-A: surcharge for notch
This calculation example can be used as a basis for other dimensions and edge designs.

Attachment table, planning example 2

for attaching to the side of the base cabinet or to the rear of a rear panel
Calculation example:
APD110: 1100 x 1100 mm,
1 x APD-K: Surcharge for rear edge allocation 550 mm,
1 x AP-R: Surcharge for rounding radius 550 mm
This calculation example can be used as a basis for other dimensions and edge designs.

Attachment table, planning example 3

Calculation example:
APD80: 1400 x 800 mm,
1 x APD-K: Surcharge for rear edge allocation 550 mm,
1 x AP-R: extra charge for rounding radius 100 mm,
1 x AP-A: Surcharge for notching
This calculation example can be used as a basis for other dimensions and edge designs.

Attachment table, planning example 4

Calculation example:
APD80: 1500 x 800 mm,
1 x APD-K: Surcharge for rear edge allocation 1660 mm,
1 x APD-A: Surcharge for bevels,
1 x AP-A: Surcharge for notch,
1 x AP-IEK: Surcharge for inside corner, angular version
This calculation example can be used as a basis for other dimensions and edge designs.

Attachment table, planning example 5

Calculation example:
APD90: 1600 x 900 mm,
1 x APD-K: Surcharge for rear edge allocation 700 mm,
1 x AP-R: Surcharge for rounding radius 450 mm,
1 x AP-A: Surcharge for notching
This calculation example can be used as a basis for other dimensions and edge designs.
